Getting Started
Removing and replacing the server panels
25
Removing the side panel (for pedestal models)
Follow these steps to remove a side panel.
1 Shut down the server and turn off the power switch if it is in operation.
2 If your server is an EPS model, unplug the power cable.
3 If your server is an EPS-R model, turn off the DC operate switch on the
back of the server, and then unplug the power cable.
4 Release the security lock and open the upper and lower front doors.
5 Turn the side panel lock key counterclockwise to the horizontal position to
release the lock.
Releasing the side panel lock
6 Slide the side panel by about 0.5 inches (1 cm) toward the rear of the server
to remove it from the server.
Removing a side panel
