Page 89

Installing and Removing Hardware

CPU Module

two lines.
(The example below shows the case of 700 MHz, 2-CPU configuration.)

16 Insert a Sensor Data and LCD Setup Tool floppy disk and restart the system.

17 Select “4. Setup CPU FAN Sensor (for MAGNIA 3030)”.

The CPU fan sensor information on the mother board is set automatically.

18 If message “Press any key to continue...” appears, remove the floppy disk

and turn off the power.

NOTE: When a CPU module is extended, the operating system (OS) may
have to be reinstalled for recognition of a new CPU module.
The CPU modules with different CPU speeds cannot be used together. Con-
firm the CPU speed of your model when purchasing a CPU module, and be
sure to purchase a CPU module with the same CPU speed.

If the CPU modules with different CPU speeds coexist, the message below is
displayed during activation. Confirm that the message below is not displayed.

Replacing the CPU Module

NOTE: The CPU module may be fatally damaged by static electricity because
it is precise electronic parts. The human body contains slight static electricity.
Therefore, discharge the static electricity before installing the CPU module.
Static electricity can be discharged by only touching a near-by metallic object
with your fingers.

Phoenix BIOS 4.0 Release6.0

L440GX0.86B.XXXX.XXXXXXXXXXXXX

L440GX+ Production Release XX.X

BIOS Build XXX

Intel(R) Pentium (R) III Processor 700eMHz

XXXXXXXX Extended Memory ECC Initialized

8181:Mismatch among Processors Detected
