Installing and Removing Hardware

Cooling Fan

Installing a cooling fan (additional installation)

Before starting the job to install a cooling fan (additional installation), carefully
read “Before starting operation” of this chapter and proceed to the job accord-
ing to the following procedure.

1 If the server is in operation, shut it down first and cut off the power supply to

it.

2 For the EPS model, unplug the power cable from the AC outlet.

3 For the EPS-R model, turn off the DC operate switch on the back of the

server first and then unplug the power cable from the AC outlet.

NOTE: If the cooling fan is removed as the server is turned on, the service life
of the fan and server may be shortened.

4 Remove the panels from the server.

See “Removing and replacing the server panels” on page 24

5 Remove the screws fastening the spacer for the suction/exhaust fan modules

and then remove the spacer.

6 Set redundant suction/exhaust fan modules in the server and fasten them

with the screw.

7 Connect the cables between the additionally installed fan modules and

SMC board.

For connecting the basic suction fan module, connect the cables to the
FAN#1 and FAN#2 connectors on the SMC board.
For connecting the redundant suction fan module, connect the cables to the
FAN#3 and FAN#4 connectors on the SMC board.
For connecting the basic exhaust fan module, connect the cable to the
FAN#5 connector on the SMC board.
For connecting the redundant exhaust fan module, connect the cable to the
FAN#6 connector on the SMC board.
