System Configuration Setup
SSU (System Setup Utility)
111
See “Removing and replacing the server panels” on page 24.
3 Insert a PCI expansion card into a vacant PCI slot.
4 Switch on the server and start the SSU (System Setup Utility).
5 Select “Resources” from the “Task” menu.
6 Select “Resource Use” that is shown when an item is selected from the
“Devices” menu, and check the resource.
Change selection of the resource depending on the situation and select
“OK” .
7 If you change the setting, select “Save” to save the new data on the changed
system configuration.
8 Restore the removed panels to the server.
9 Restart the server and check to see if no error message appears on the dis-
play.
Since the resource of the PCI expansion card is automatically set up, it is not
always needed to start the SSU. However, execute the item of “Resources”
to check or change the resource depending on the situation. If the ISA
expansion card (without CFG file) is installed, there is a fear that the PCI
expansion card and ISA expansion card may conflict with each other and
the system may fail in normal operation. If this trouble occurs, remove the
ISA expansion card and change the resource according to the procedure of
“Installation of ISA Expansion card (without CFG file)” and “Removing
ISA Expansionexpansion card (without CFG file)”.
Removing PCI Expansion Card
For removing a PCI expansion card, follow the procedure mentioned below.
1 If the server is in operation, shut it down and unplug the power cable after
cutting off the power supply.
2 Remove the panels from the server.
See “Removing and replacing the server panels” on page 24.
3 Remove the PCI expansion card from the PCI slot.
4 Restore the panels to the server.
