Getting Started
Front view (with the front doors opened)
19
NOTE: When a Status lamp is lit amber, the corresponding hard disk drive
may be faulty. If it is found to be defective, replace it. If your system has a
built-in RAID controller, you can replace the faulty drive without interrupting
the system operation.
Shock and vibration might damage hard disk drives, causing the loss or
corruption of the data and programs recorded on them. So always handle
them carefully.
Installing and replacing a hard disk drive requires special techniques and
knowledge. So instead of installing or replacing it yourself, ask an authorized
Magnia service provider for it.
An error committed during installation or replacement, especially when the
system is running, might result in a system failure and/or the corruption or
loss of important data and programs.
Keep hard disk drives free from shock and vibration, especially when they are
on. Even if the Status lamp is off, its magnetic head remains in the data area
and, if a shock is given, it might destruct the data area.
When the server is switched off, the magnetic head of each hard disk drive
automatically retracts. Note that it takes about 30 seconds for a hard disk drive
to stop completely.
See “(7) Hard disk drive” on page 18.
Side panel lock
Releasing the side panel lock allows you to remove the side panel, and make
access to the internal components.
Lower door security
The lower door provides access to the hard disk drives and the side panel lock.
