Installing and Removing Hardware
CPU Module
67
CPU Module
The server is classified into 3 models that differ in the processing speed
(600EMHz, 700 MHz, 800Hz) of the CPU from each other. If a CPU module
that is the same in the processing speed as the standard CPU mounted in your
server is additionally installed, the server is transformed into an upgraded ver-
sion having two CPUs (in maximum). A CPU that is different in the processing
speed from the standard one cannot be used for additional installation. There is
a slot (No. 2 slot) for installing an extension CPU at the left side of the slot (No.
1 slot) for the standard CPU.
To install a CPU with a different processing speed, it is necessary to remove and
replace all current CPUs with others with the same processing speed.
CPU slots
WARNING: When installing a peripheral unit, don’t open any part other than
those specified by the instructions. If an unspecified part is opened, it may
cause an electric shock.
Installing the CPU Module
NOTE: The CPU module may be fatally damaged by static electricity because
it is precise electronic parts. The human body contains slight static electricity.
Therefore, discharge the static electricity before installing the CPU module.
Static electricity can be discharged by only touching a near-by metallic object
with your fingers.
CPU slot 2 CPU slot 1 (for the standard CPU)
