Getting Started
Front view (with the front doors opened)

NOTE: To use the sleep switch, enable it in advance, using Sensor Data and
LCD Setup Tool.
See “Sensor Data and LCD Setup Tool” on page 146.

In security mode, the power switch and the reset switch are inoperative. To
enable these switches, you need to enter the user password.

The way to switch on and off the server varies depending on the OS installed on
it.
See “Switching On the Server” on page 39 and “Switching Off the Server” on
page 47.

(6) System status indicators

This server has 4 operating status indicators (lamps) on the front panel.

System status indicators

Power lamp ( )

Disk lamp ( )

Auto SD/Remote lamp ( )

Fault lamp ( )

Off
