Installing and Removing Hardware
Hard Disk Drive (HDD) 90
3 Tilt over the detachable lever of the slot which holds a defective hard disk
drive, by pulling its knob marked PULL toward you.
Pulling the detachable lever toward you
4 Pull out the partially extracted hard disk drive carefully by both hands.
Removing the hard disk drive
NOTE: Before pulling out the hard disk drive, make sure that it is faulty. If a
normally operating device is pulled out by mistake, it may damage the server
or destroy and lose important programs or data.
5 Install a new hard disk drive in the same procedure as for extension.
See “Installing the hard disk drive” on page 87.
6 After a short time, confirm that the DC POWER lamp ( ) lights up.
7 Close the front doors (upper and lower).
Disk tray
