Smart Managed Pro Switches MS510TX and MS510TXPP

Maintain the Switch and Perform

Troubleshooting

User Manual

315

To reset the switch to the factory default settings:

1.

Connect your computer to the same network as the switch.

You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.

2.

Launch a web browser.

3.

In the address field of your web browser, enter the IP address of the switch.

If you do not know the IP address of the switch, see

Access the Switch on page

14

.

The login window opens.

4.

Enter the switch’s password in the

Password

field.

The default password is

password

.

The System Information page displays.

5.

Select

Maintenance > Reset > Factory Default

.

The Factory Default page displays.

6.

Select the check box.

7.

Click the

Apply

button.

A confirmation pop-up window opens.

8.

Click the

Yes

button to confirm.

All configuration settings are reset to their factory default values. All changes that you

made are lost, even if you saved the configuration.

Export a File From the Switch

The switch supports system file exports from the switch to a remote system by using either
TFTP, HTTP or USB.

The

Maintenance > Export

menu contains links to the features described in the following

sections.

Export a File to the TFTP Server on page

315

HTTP File Export on page

317

Export a File From the Switch to a USB Device on page

318

Export a File to the TFTP Server

Use the TFTP File Export page to export configuration (ASCII), log (ASCII), and image
(binary) files from the switch to a TFTP server on the network.
