Smart Managed Pro Switches MS510TX and MS510TXPP

Monitor the System

User Manual

312

5.

Select

Monitoring > Mirroring > System Resource Utilization

.

The System Resource Utilization page displays. The page also shows the Used
Resources section.

6.

To refresh the page with the latest information about the switch, click the

Refresh

button.

The following table describes the nonconfigurable information displayed on the page.

Table 72. System Resource Utilization and Used Resources information

Field

Description

System Resources Utilization

The percentage of total TCAM utilization on the switch.

Max System Resource Entries

The maximum number of TCAM entries that are available on the switch.

ACLs

The number of TCAM entries that are used by ACLs.

DiffServe

The number of TCAM entries that are used by DiffServe.

DVA

The number of TCAM entries that are used by Dynamic VLAN Assignment
(DVA).

DHCP Snooping

The number of TCAM entries that are used by DHCP snooping.
