Smart Managed Pro Switches MS510TX and MS510TXPP
Configure Quality of Service
User Manual
215
The following table describes the nonconfigurable information displayed on the page.
Remove a DiffServ Policy From an Interface
To remove a DiffServ policy from an interface:
1.
Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2.
Launch a web browser.
3.
In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
The login window opens.
4.
Enter the switch’s password in the
Password
field.
The default password is
password
.
The System Information page displays.
5.
Select
QoS > DiffServ > Advanced > Service Configuration
.
The Service Interface Configuration page displays.
6.
Select the check boxes that are associated with the interfaces from which you want to
remove the policy.
7.
From the
Policy In Name
menu, select
None
.
8.
Click the
Apply
button.
Your settings are saved.
View DiffServ Service Statistics
You can display service-level statistical information about all interfaces to which DiffServ
policies are attached.
To view the DiffServ service statistics:
1.
Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
Table 53. Service Interface Configuration information
Field
Description
Direction
Shows that the traffic direction of this service interface is In.
Operational Status
Shows the operational status of this service interface, which is always Up.
