5.6 Evaluation subwindow
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
582 ￭￭￭￭￭￭￭￭
viva 1.0
RS.'Command name'.ASU.'Result name'[.VAL] (ASU = All substan-
ces; multiple result).
Entry 40 characters
Default value 'empty'
Properties
Formula
Field for the calculation formula that can either be edited directly or be
created with the formula editor by clicking on the symbol . The for-
mula defines the type (Number, Text or Date/Time) of the result.
After the formula has been defined, it is mandatory that the suitable unit
be selected for the result.
Unit
Unit of the calculated result for the output (text only) that can be reused
under the designationRS.'Command name'.'Substance name'.'Re-
sult name'.UNI (single result) or RS.'Command name'.ASU.'Result
name'.UNI (ASU = all substances; multiple result).
Entry 60 characters
Selection g/L | mg/L | µg/L | ng/L | mol/L | mmol/L |
µmol/L | nmol/L | pmol/L | mL/L | µL/L | nL/L
Default value mL/L
Decimal places
Number of decimal places for the output of the calculated result. This
parameter is ignored for results of the Text or Date/Time type.
Input range 0 - 6
Default value 3
Assignment
Assignment of the result to one of the 25 possible result columns.
Selection RS01 - RS25 | none
RS01 - RS25
Assignment of the single result to one of the 25 possible result col-
umns RS01 - RS25 in the determination overview. The only columns
available for selection are those that are still free.
none
The result is not assigned to a result column and is displayed only in
the Results subwindow.
