Rockwell Automation 20Y PowerFlex 700H, 700S, and 700AFE Drive Fan Systems, Frames 9...14 User Manual
Page 34
34
Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Chapter 1
PowerFlex 700H and 700S Drives - Frame 9 Procedures
8.
Remove the three M4 x 8 mm POZIDRIV screws that hold the fan
inverter assembly to the drive and remove the fan inverter assembly.
1
2
3
4
ON
X6
X1
X4
X5
X7
S1
X2
X8
Fan Inverter Circuit Board
PZ2
3.0 N
•
m (27 lb
•
in)
8
