Rockwell Automation 20Y PowerFlex 700H, 700S, and 700AFE Drive Fan Systems, Frames 9...14 User Manual
Page 260
260
Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Appendix A
PowerFlex 700H and 700S Diagnostic Procedures
Figure 36 - Frame 10 AFE Fan System Topology (New Style)
+/- DC Bus
Fuse
Fuse
DC Fan
ASIC Circuit
Board
X2
X8
X81
X3
X11
DC Fan
DC Fan Power
Supply Circuit
Board
(LCL Filter
Section)
DC Fan Power
Supply Circuit
Board
(power Structure
Section)
