Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Chapter 8
PowerFlex 700AFE Drive - Frame 13 Procedures
Frame 13 AFE Drive
Configurations
Frame 13 AFE drive consists of a LCL filter section and a converter section. The
converter section is an inverter section designed to either supply DC bus voltage
or regenerate power back to the AC line. For clarity of instructions, the converter
will be referred to as a power structure throughout this chapter.
Figure 27 - Frame 13 AFE System - IP21 NEMA / UL Type 1 (Rittal) Cabinet
LCL Filter DC Fan Fuses
Inverter Fan Fuses
