Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014

187

PowerFlex 700AFE Drive - Frame 10 Procedures

Chapter 7

Frame 10 AFE Fan System
Spare Parts

AC Fan Systems

See Available Fan System Kits starting on page

277

for an illustration of the spare

part kit contents.

Voltage

Cat. No.

Part Description

Quantity
per
Drive

Original Vendor and
Model Number

Power
Structure

20-FI13300

Main AC fan assembly

1

20-FI13301

AC fan inverter assembly (includes
PCB, fuses capacitor, isolation
transformer, and mounting
hardware)

1

20-PP1096

Cooling fan for ASIC board assembly

1

Sinwan SD5012PT-24H

(1)

(1) The part may not contain wires, connectors, or mounting hardware when bought directly from vendor.

20-PP20202 (2)

Fuse for fan system

2

Ferraz Shawmut ATQ8

(2)

(2) The factory default fuses are Ferraz Shawmut ATQ8, 8 A fuses. Older drives may contain Bussman 6 A fuses.

20-PP20300

Fuse holder for main fan system fuses

1

Ferraz Shawmut 30322

20-VB00299

AC fan inverter circuit board

1

SK-H1-FANCAP-F1314

AC fan capacitor kit

1
