Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014 235
Chapter
8
PowerFlex 700AFE Drive - Frame 13 Procedures
This chapter contains spare part information and procedures for testing and
replacing fan system components for frame 13 PowerFlex 700AFE drives. See
Appendix A PowerFlex 700H and 700S Diagnostic Procedures on page
255 for
additional component test procedures.
Topic Page
Frame 13 AFE Drive Configurations 236
Frame 13 AFE Fan System Spare Parts 238
Tools Needed for Frame 13 AFE Fan System Repairs 239
Frame 13 AFE Schematic Diagrams 240
Frame 13 AFE Fan System Replacement Procedures 243
Power Structure Section 243
LCL Filter Section 243
Removing the LCL Filter Protective Cover 244
LCL Filter DC Fan Fuses (20-PP20202) Removal and Installation 245
LCL Filter DC Fan Power Supply (SK-Y1-DCPS1-D1K3 or SK-Y1-DCPS1-E1K0) Removal
and Installation 245
LCL Filter Fan DC Power Supply (SK-Y1-DCPS2-F13) Removal and Installation 247
LCL Filter Fan DC Power Supply Circuit Board (SK-H1-DCFANBD1) Removal and
Installation 249
LCL Filter Fan Assembly Removal and Installation 252
LCL Filter Main DC Fan (SK-Y1-DCFAN1) Assembly Removal and Installation 253
