Figure 12 – Rockwell Automation 20Y PowerFlex 700H, 700S, and 700AFE Drive Fan Systems, Frames 9...14 User Manual
Page 128
128
Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Chapter 5
PowerFlex 700H and 700S Drives - Frame 13 Procedures
Figure 12 - Frame 13 AC Input Drive Converter DC Fan System
Rectifier
Circuit
Board
X201
4
Main DC Fan
Fan Module
DC +
DC -
Isolated 48 VDC Power
Supply Circuit Board
X81
X8
X3
X82
X2
X1
To Next
Fan Module
