Rockwell Automation 20Y PowerFlex 700H, 700S, and 700AFE Drive Fan Systems, Frames 9...14 User Manual
Page 226
226
Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Chapter 7
PowerFlex 700AFE Drive - Frame 10 Procedures
4.
Remove the two M4 x 8 mm POZIDRIV screws that secure the cover to
the chassis and remove the cover.
5.
Disconnect the cables from connectors X2, X3 and X8 at the top of the
board.
4
Image for SK-Y1-DCPS2-F10
X8
X2
X3
Image for SK-H1-DCFANBD1
