Chapter 7
PowerFlex 700AFE Drive - Frame 10 Procedures
1.
Review the General Precautions on page
2.
Remove power from the AFE. See Remove Power from the AFE on page
3.
Remove the LCL filter fan. See LCL Filter Fan Assembly Removal and
Installation on page
.
X51
X53
Image for SK-Y1-DCPS2-F10
