Rockwell Automation 20Y PowerFlex 700H, 700S, and 700AFE Drive Fan Systems, Frames 9...14 User Manual
Page 190
190
Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Chapter 7
PowerFlex 700AFE Drive - Frame 10 Procedures
Figure 22 - Frame 10 AFE (Power Structure) DC Fan System Wiring Schematic Diagram
To ASIC Circuit Board X11
(Fan Control)
3
4
Main DC Fan
Fan Module
DC +
DC -
Isolated 48 VDC Power
Supply Circuit Board
X81
X8
X3
X82
X2
To X51 on the LCL Filter
Power Supply Circuit
Board
