20 Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Chapter 1 PowerFlex 700H and 700S Drives - Frame 9 Procedures
Frame 9 Fan System Spare
Parts AC Fan Systems
See Available Fan System Kits starting on page 277 for an illustration of the spare
part kit contents.
DC Fan Systems
See Available Fan System Kits starting on page 277 for an illustration of the spare
part kit contents.
Tools Needed for Frame 9 Fan
System Repairs • #2 Phillips head screwdriver
• #2 POZIDRIV screwdriver
• Flat blade screwdriver
• 13 mm socket wrench
• 19 mm socket wrench
• T20 hexalobular screwdriver with a shaft length of at least 9 cm (3.54 in.)
• Cable ties
• Electrical tape
• Fuse puller
• Multi-meter
• Needle-nose pliers
Cat. No. Part Description Quantity
per Drive Original Vendor and
Model Number
(3)
(3) This part may not contain wires, connectors, or mounting hardware when bought directly from the vendor.
20-PP01049 50 mm cooling fan for fan inverter 1 Sinwan
SD5012PT-24H
20-PP01068 80 mm x 80 mm x 32 mm internal stirring fan
assembly 2 or 3
(2)
(2) 2 for PowerFlex 700H drives and 3 for PowerFlex 700S drives.
Japan Servo Co., LTD
PUDC24H4C-049
20-PP01080 230 W Main AC fan assembly 1 –
20-PP09055 Output transformer for main fan inverter 1 –
20-PP20202 Fuse for fan system 2 Ferraz Shawmut
ATQ8
(4)
(4) The factory default fuses are Ferraz Shawmut ATQ8, 8 A fuses. Older drives may contain Bussman 6 A fuses.
20-PP20300 Fuse holder for main fan system fuses 1 Ferraz Shamut 30322
20-VB00299 Main fan inverter circuit board
(1)
(1) The same part and catalog number is used for both 400/480V AC and 600/690V AC input drives.
1 –
SK-H1-FANCAP-F9 Capacitor (7
μF) for main fan inverter
1 –
SK-H1-FR9BRKT AC fan bracket 1 –
Cat. No. Part Description Quantity
per Drive Original Vendor and
Model Number
SK-Y1-DCFAN1 Main DC fan assembly 1 –
SK-H1-DCFANBD1 Main DC fan power supply circuit board
(1)
(1) Circuit Board only, no sheet metal bracket.
1 –
SK-H1-DCFANRETROFIT-F9 AC to DC fan system retrofit kit 1 –
