Page 243: Lcl filter section ta, Power structure section lcl filter section

Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014

243

PowerFlex 700AFE Drive - Frame 13 Procedures

Chapter 8

Frame 13 AFE Fan System
Replacement Procedures

Replacement procedures for these frame 13 fan system parts are included in this
chapter.

Power Structure Section

The frame 13 PowerFlex 700AFE power structure is essentially a PowerFlex
700H or PowerFlex 700S frame 13 DC input drive. The procedures for replacing
PowerFlex 700AFE frame 13 fan system components are the same as those for
frame 13 drives. See Frame 13 Fan System Replacement Procedures beginning on
page

134

for detailed replacement procedures.

LCL Filter Section

The LCL filter provides the filtering to minimize the harmonic content
originating from the inverter section (PWM frequency) from interacting with
the ac grid.

Replacement procedures for these frame 13 AFE LCL filter fan system parts are
included in this chapter.

Note:

Additional procedures will be added to future revisions of this publication

as they become available. Enter ‘PFLEX-IN029’ in the Search field on the
Rockwell Automation Literature Library at:

http:/www.rockwellautomation.com/literature/

Cat. No.

Part Description

Page

20-PP01096

60 mm cooling fan for the ASIC board assembly

139

20-PP20202
