Rockwell Automation 20Y PowerFlex 700H, 700S, and 700AFE Drive Fan Systems, Frames 9...14 User Manual
Page 159
Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
159
PowerFlex 700H and 700S Drives - Frame 13 Procedures
Chapter 5
8.
Secure the power supply cables to the inside of the main fan housings using
the cable ties supplied with the kit.
9.
Route the fan inverter power supply cables through the hole in the drive
chassis and insert them into the connector support bracket on the front of
the drive chassis.
8
Inverter section shown
9
Inverter section shown
