PowerFlex 700H and 700S Drives - Frame 13 Procedures
Chapter 5
Frame 13 Fan System Spare
Parts
AC Fan Systems
See Available Fan System Kits starting on page
for an illustration of the spare
part kit contents.
Input Voltage:
Catalog Number:
Part Name:
Quantity Per Drive:
(1)
Original Vendor and Model No.
400/480
20-FI13301
AC fan inverter assembly (includes circuit board, fuses,
capacitor, isolation transformer, and mounting
hardware)
DC Input
3
AC 1150 Amp
5
AC 1300 / 1450 Amp
6
20-VB00299
AC fan inverter circuit board
DC Input
3
AC 1150 Amp
5
AC 1300 / 1450 Amp
6
20-FI13300
Main AC fan assembly
DC Input
3
AC 1150 Amp
5
AC 1300 / 1450 Amp
6
SK-H1-FANCAP-F1314
Main AC fan capacitor kit
DC Input
3
AC 1150
5
AC 1300 / 1450 Amp
6
20-PP20300
Fuse holder for main fan system fuses
DC Input
3
Ferraz Shawmut 30322
AC 1150 Amp
5
AC 1300 / 1450 Amp
6
20-PP20202
Fuse for fan system
DC Input
6
Ferraz Shawmut ATQ8
(2)
AC 1150 Amp
10
AC 1300 / 1450 Amp
12
20-PP1096
Cooling fan for ASIC board assembly
all
1
Sinwan SD5012PT- 24H
(3)
600/690
20-FI13301
AC fan inverter assembly (includes circuit board, fuses,
capacitor, isolation transformer, and mounting
hardware)
DC Input
3
AC Input
5
20-VB00299
AC fan inverter circuit board
DC Input
3
AC Input
5
20-FI13300
Main AC fan assembly
DC Input
3
AC Input
5
SK-H1-FANCAP-F1314
AC fan capacitor kit
DC Input
3
AC Input
5
20-PP20300
Fuse holder for main fan system fuses
DC Input
3
Ferraz Shawmut 30322
AC Input
5
20-PP20202
Fuse for fan system
DC Input
6
Ferraz Shawmut ATQ8
(2)
AC Input
10
20-PP1096
Cooling fan for ASIC board assembly
All
1
Sinwan SD5012PT- 24H
(3)
(1) The drives are identified by voltage class (400/480 or 600/690) and then by the current rating - 920…1450 A
(2) The factory default fuses are Ferraz Shawmut ATQ8, 8 A fuses. Older drives may contain Bussman 6 A fuses.
(3) The part may not contain wires, connectors, or mounting hardware when bought directly from vendor.
