Rockwell Automation 20Y PowerFlex 700H, 700S, and 700AFE Drive Fan Systems, Frames 9...14 User Manual
Page 172
172
Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Chapter 5
PowerFlex 700H and 700S Drives - Frame 13 Procedures
7.
Disconnect the fan capacitor wires from the connectors marked “Brown”
and “Blue.”
8.
Unscrew and remove the existing fan capacitor from the inverter assembly.
7
AC fan inverter shown.
AC fan inverter shown.
