Rockwell Automation 20Y PowerFlex 700H, 700S, and 700AFE Drive Fan Systems, Frames 9...14 User Manual
Page 106
106
Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014
Chapter 3
PowerFlex 700H and 700S Drives - Frame 11 Procedures
Follow these steps to remove, test, and replace the main AC fan inverter
capacitor.
1.
Review the General Precautions on page
2.
Remove power from the drive. See Remove Power from the Drive on page
.
3.
Move the control frame and remove the air flow plate and protective
covers from the drive. See Move the Control Frame and Remove the Air
Flow Plate and Protective Covers on page
.
4.
Remove the appropriate main AC fan inverter assembly. See Removing the
Main AC or DC Fan Power Supply Assemblies on page
.
