Rockwell Automation Publication PFLEX-IN029B-EN-P - August 2014

255

Appendix

A

PowerFlex 700H and 700S Diagnostic Procedures

The following diagnostic procedures can be used to determine whether specific
fan system components require replacement.

Topic

Page

Fan Inverter System Block Diagrams

257

Checking the Fan Inverter Fuses

263

Checking the Main Fan Supply Wires

264

Checking the AC Fan Inverter Capacitor

265

Isolating a Faulty Fan Inverter

265

Checking the Main AC Fan Inverter Circuit Board Diagnostic LEDs

268

Testing the Main Fan Inverter Circuit Board Diagnostic LEDs

274
