Stabil-TRAK™ System and Boom Interlock System
10.4 Model 8042, 10042, 10054 Legacy Rev. 10/03
10.2 BOOM EXTEND INTERLOCK
SYSTEM COMPONENT
TERMINOLOGY (10054 ONLY)
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the boom extend
interlock system. The following illustration identifies the
components that are referred to throughout this section.
MH3001
Boom Extend
Sensor
Outrigger Cylinder
Pressure Switch (2)
Boom Lockout
Valve
~
