Electrical System
9.58 Model 8042, 10042, 10054 Legacy Rev. 10/03
62
9.62,
9.63,
9.64 or
9.65
16 PUR/WHT Right Outrigger Switch Connector (Pin 3) to Outrigger Valve Solenoid (Right Down) (Pin 1)
63
9.62,
9.63,
9.64 or
9.65
16 BRN/YEL Left Outrigger Switch Connector (Pin 1) to Outrigger Valve Solenoid (Left Up) (Pin 1)
64
9.62,
9.63,
9.64 or
9.65
16 GRY/PUR Left Outrigger Switch Connector (Pin 3) to Outrigger Valve Solenoid (Left Down) (Pin 1)
101
9.62 or
9.64
16 BRN Shifter Connector (Pin 5) to Cab/Chassis Male Connector (Pin C1) (Cab Harness)
9.63 or
9.65
16 BRN Cab/Chassis Female Connector (Pin C1) to Splice 101 (Engine Harness)
101A
9.63 or
9.65
16 BRN Splice 101 to Diode VESPAK (Pin B)
101B
9.63 or
9.65
18 BRN Splice 101 to Lower Transmission Connector (Pin 5, Solenoid Y5)
102
9.62 or
9.64
16 PNK Splice 102 to Cab/Chassis Male Connector (Pin C2) (Cab Harness)
9.63 or
9.65
16 PNK Cab/Chassis Female Connector (Pin C2) to Splice 102 (Engine Harness)
102A
9.62 or
9.64
16 PNK Splice 102 to Shifter Connector (Pin 3) (Cab Harness)
9.63 or
9.65
16 PNK Splice 102 to Diode VESPAK (Pin E) (Engine Harness)
102B
9.62 or
9.64
16 PNK Splice 102 to Back-Up Alarm Relay (Pin 86) (Cab Harness)
9.63 or
9.65
18 PNK Splice 102 to Upper Transmission Connector (Pin 2, Solenoid Y2) (Engine Harness)
103
9.62 or
9.64
16 BLU Shifter Connector (Pin 7) to Cab/Chassis Male Connector (Pin C3) (Cab Harness)
9.63 or
9.65
16 BLU Cab/Chassis Female Connector (Pin C3) to Splice 103 (Engine Harness)
103A
9.63 or
9.65
16 BLU Splice 103 to Diode VESPAK (Pin A)
103B
9.63 or
9.65
18 BLU Splice 103 to Upper Transmission Connector (Pin 3, Solenoid Y3)
104
9.62 or
9.64
16 YEL Shifter Connector (Pin 2) to Cab/Chassis Male Connector (Pin C4) (Cab Harness)
9.63 or
9.65
16 YEL Cab/Chassis Female Connector (Pin C4) to Splice 104 (Engine Harness)
104A
9.63 or
9.65
16 YEL Splice 104 to Diode VESPAK (Pin E)
104B
9.63 or
9.65
18 YEL Splice 104 to Upper Transmission Connector (Pin 1, Solenoid Y1)
105
9.62 or
9.64
16 GRN Shifter Connector (Pin 6) to Cab/Chassis Male Connector (Pin C5) (Cab Harness)
9.63 or
9.65
16 GRN Cab/Chassis Female Connector (Pin C5) to Splice 105 (Engine Harness)
105A
9.63 or
9.65
16 GRN Splice 105 to Diode VESPAK (Pin B)
105B
9.63 or
9.65
18 GRN Splice 105 to Lower Transmission Connector (Pin 4, Solenoid Y4)
Wire No. Page Gauge Color From - Function - To
† SN 13198 through 16782 w/o Lighting Package
§ SN 13198 through 16782 w/Lighting Package and SN 16783 through 19030
