General Information and Specifications
2.20 Model 8042, 10042, 10054 Legacy Rev. 10/03
2.5.4 Performance Specifications
Note: Performance criteria is based on full throttle engine speed unless otherwise specified or not applicable.
2.5.5 Hydraulic Cylinder Performance Specifications
Note: Vehicle with no load, engine at full throttle, hydraulic oil above 130° F (54° C) minimum, engine at operating
temperature.
Travel Speed (Standard Tires, No Load) All Models
First Gear 0-3.5 mph (0-5,6 km/hr)
Second Gear 0-6 mph (0-9,7 km/hr)
Third Gear 0-14 mph (0-21,7 km/hr)
Fourth Gear 0-20 mph (0-32,2 km/hr)
Function Approximate Times, in Seconds
8042 10042 10054
Boom Extend Less than 19.0 Less than 19.0 Less than 19.0
Boom Retract Less than 17.0 Less than 17.0 Less than 17.0
Boom Lift Retracted Less than 17.5 Less than 17.5 Less than 17.5
Boom Lower Retracted Less than 15.5 Less than 15.5 Less than 15.5
Attachment Tilt - UP Less than 8.0 Less than 8.0 Less than 8.0
Attachment Tilt - DOWN Less than 11.0 Less than 11.0 Less than 11.0
Frame Sway Left to Right with Boom
Down 5.5-12.0 5.5-12.0 3-6
Frame Sway Left to Right with Boom
Above 40
° and Emergency Brake
Engaged
23.0-33.0 23.0-33.0 23.0-33.0
Frame Sway Right to Left with Boom
Down 4.0-8.0 4.0-8.0 4.0-8.0
Frame Sway Right to Left with Boom
Above 40
° and Emergency Brake
Engaged
26.0-52.0 26.0-52.0 26.0-52.0
Outrigger - Left or Right, UP or DOWN — 4.0-9.0 4.0-9.0
Outrigger - Left and Right, UP or DOWN — 4.0-10.0 4.0-10.0
