10.3 Model 8042, 10042, 10054 Legacy Rev. 10/03
Stabil-TRAK™ System and Boom Interlock System
10.1 STABIL-TRAK™ SYSTEM
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the Stabil-TRAK™
system. The following illustration identifies the
components that are referred to throughout this section.
MH2961
Boom Proximity
Switch
Frame Sway
Cylinder
Stabil-TRAK™
Cylinder
Stabil-TRAK™
Manifold
Model 10054 Shown
