Axles, Drive Shafts, Wheels and Tires
5.12 Model 8042, 10042, 10054 Legacy Rev. 10/03
10. If reinstalling an axle previously removed from the
vehicle, position the driveshaft yoke on the axle
according to the alignment marks made earlier. If
installing a new axle, note the position of the
driveshaft yoke at the transmission. Align the
driveshaft yoke on the axle in the same plane as the
yoke on the transmission.
11. Install the wheel and tire assemblies. (Refer to
Section 5.5.4, “Installing Wheel and Tire Assembly
onto Vehicle.”)
12. Carefully remove the jack, hoist or overhead crane
and sling supporting the axle.
13. Carefully raise the vehicle using a suitable jack or
hoist. Remove the supports from beneath the frame
and lower the vehicle to the ground.
14. Remove the blocks from the front and rear of both
tires on the other axle.
Note: ALWAYS use new o-rings when servicing the
vehicle.
15. Install new o-rings into the fittings. Lubricate the
o-rings with clean hydraulic oil.
16. Uncap and connect the steering and brake lines at
their axle fittings.
17. Models 10042 and 10054, Front Axle Only: Install
outrigger assembly. Refer to Section 5.3.6, b.
“Outrigger Installation.”
18. Check the hydraulic reservoir oil level.
19. Start the engine. Turn the steering wheel several
times lock to lock, operate the frame tilt function
several times in both directions and check the
function of the brakes. Check for hydraulic leaks, and
tighten or repair as necessary.
5.3.7 Axle Service and Troubleshooting
This section provides an easy reference guide covering
the most common problems that may occur during
operation of the axles.
Note: Contact the Sky Trak distributor or the JLG
Service Department at 1-877-554-5438 or
1-717-485-6657, if internal axle repair is required during
the warranty period.
Detailed axle service instructions (covering the axle,
differential, brakes and wheel-end safety, repair,
disassembly, reassembly, adjustment and
troubleshooting information) are provided in the ZF Axle
Repair Manuals. (Refer to Section 5.3.8, “ZF Axle Repair
Manuals.”)
The axle should be checked, serviced and repaired only
by experienced service technicians who are aware of all
safety instructions and particular component features.
WARNING:
Avoid prolonged engine
operation in closed areas without adequate
ventilation. Failure to properly ventilate
exhaust fumes can result in death or severe
personal injury.
WARNING:
Escaping hydraulic fluid
under pressure can penetrate the skin, causing
death or serious injury. Before starting the
engine, tighten all hydraulic connections and
remove all tools from the vehicle. NEVER
check for leaks using any part of the human
body; use a piece of cardboard or wood
instead. Wear heavy, protective gloves and
eye protection.
