Electrical System
BP 9.104 16 RED/GRN
10 amp Mini Fuse VESPAK Connector P6 (Pin F)
to Engine Control Module, Male Diagnostic Connector, P7 (Pin B)
BP1 9.104 16 RED/GRN Battery 2, Positive (+) Terminal to 10 amp Mini Fuse VESPAK Connector P6 (Pin E)
BPB 9.104 16 RED/WHT
7.5 amp Mini Fuse VESPAK Connector P5 (Pin B)
to Engine Control Module, Female Engine Connector, P1 (Pin B)
BPB1 9.104 16 RED/WHT Battery 2, Positive (+) Terminal to 7.5 amp Mini Fuse VESPAK Connector P5 (Pin A)
BPC 9.104 16 RED/WHT
7.5 amp Mini Fuse VESPAK Connector P5 (Pin D)
to Engine Control Module, Female Engine Connector, P1 (Pin C)
BPC1 9.104 16 RED/WHT Battery 2, Positive (+) Terminal to 7.5 amp Mini Fuse VESPAK Connector P5 (Pin C)
BPD 9.104 16 RED/WHT
7.5 amp Mini Fuse VESPAK Connector P5 (Pin F)
to Engine Control Module, Female Engine Connector, P1 (Pin D)
BPD1 9.104 16 RED/WHT Battery 2, Positive (+) Terminal to 7.5 amp Mini Fuse VESPAK Connector P5 (Pin E)
BPM 9.104 14 RED/GRN
10 amp Mini Fuse VESPAK Connector P6 (Pin B)
to Engine Control Module, Female Engine Connector, P1 (Pin M)
BPM1 9.104 14 RED/GRN Battery 2, Positive (+) Terminal to 10 amp Mini Fuse VESPAK Connector P6 (Pin A)
BPS 9.104 14 RED/GRN
10 amp Mini Fuse VESPAK Connector P6 (Pin D)
to Engine Control Module, Female Engine Connector, P1 (Pin S)
BPS1 9.104 14 RED/GRN Battery 2, Positive (+) Terminal to 10 amp Mini Fuse VESPAK Connector P6 (Pin C)
9.104 6 RED 125 Amp Fuse to Grid Heater Relay 2 (Pin 2)
CG1 9.104 16 BLK Preheat Indicator Light, Female Connector, P15 (Pin 1B-) to Cab Ground Stud
CNH 9.104 18 YEL Splice 1 to Engine, Female Connector, P3 (Pin A)
CNH1 9.104 18 YEL Splice 1 to Resistor, Female Connector, P4 (Pin A)
CNH2 9.104 18 YEL Splice 4 to Engine Control Module, Male Diagnostic Connector, P7 (Pin C)
CNH3 9.104 18 YEL Splice 4 to Resistor, Female Connector, P8 (Pin A)
CNH4 9.104 18 YEL Splice 1 to Splice 4
CNL 9.104 18 GRN Splice 2 to Engine, Female Connector, P3 (Pin B)
CNL1 9.104 18 GRN Splice 2 to Resistor, Female Connector, P4 (Pin B)
CNL2 9.104 18 GRN Splice 5 to Engine Control Module, Male Diagnostic Connector, P7 (Pin D)
CNL3 9.104 18 GRN Splice 5 to Resistor, Female Connector, P8 (Pin B)
CNL4 9.104 18 GRN Splice 2 to Splice 5
CNS 9.104 18 DRAIN Splice 3 to Engine, Female Connector, P3 (Pin C)
CNS1 9.104 18 DRAIN Splice 3 to Resistor, Female Connector, P4 (Pin C)
CNS2 9.104 18 DRAIN Splice 6 to Engine Control Module, Male Diagnostic Connector, P7 (Pin E)
CNS3 9.104 18 DRAIN Splice 6 to Resistor, Female Connector, P8 (Pin C)
CNS4 9.104 18 DRAIN Splice 3 to Splice 6
CNS5 9.104 18 BLK Splice 3 to Engine Block
9.104 6 RED 125 Amp Fuse to Grid Heater Relay 1 (Pin 2)
DD 9.104 18 BLK
Engine Control Module Bulkhead, Female Connector (Pin N)
to Engine Control Module, Female Engine Connector, P2 (Pin 36)
DI 9.104 18 BLK
Engine Control Module Bulkhead, Female Connector (Pin M)
to Engine Control Module, Female Engine Connector, P2 (Pin 35)
DLP 9.104 16 WHT/RED Splice 6 to Male Connector
DLP1 9.104 16 WHT/RED Engine Function Indicator Light, Female Connector, P15 (Pin 1A+) to Splice 6
DLP2 9.104 16 WHT/RED Engine Function Indicator Light, Female Connector, P15 (Pin 2A+) to Splice 6
DLP3 9.104 16 WHT/RED Splice 6 to Female Connector
DS 9.104 18 BLK
Engine Control Module Bulkhead, Female Connector (Pin L)
to Engine Control Module, Female Engine Connector, P2 (Pin 37)
9.104 6 RED Grid Heater Relay 1 (Pin 1) to Engine Grid Heater (Pin 1)
9.104 6 RED Grid Heater Relay 2 (Pin 1) to Engine Grid Heater (Pin 2)
9.104 1/0 RED Battery 1, Positive (+) Terminal to Starter 12V Buss Bar
GH1 9.104 18 BLK Splice 8 to Engine Control Module, Female Engine Connector, P2 (Pin 41)
GH1A 9.104 16 BLK Splice 8 to Diode VESPAK Connector P10 (Pin A)
GH1B 9.104 16 BLK Splice 8 to Grid Heater Relay 1 (Pin 3)
Wire No. Page Gauge Color From - Function - To
These wires are not part of a wire harness. Refer to the appropriate Parts Manual for part number information.
