9.91 Model 8042, 10042, 10054 Legacy Rev. 10/03
Electrical System
68
9.92,
9.93 or
9.94
16 RED/BLK Right Outrigger Switch (Pin 1) to Right Outrigger Lock Relay (Pin 30)
70A
9.92,
9.93 or
9.94
16 ORG/BLK
Park Brake Interlock Relay (Pin 86)
to Male Connector at Dash Panel (Cab Harness, Wire 152A2)
70B
9.92,
9.93 or
9.94
16 ORG/BLK Park Brake Interlock Relay (Pin 86) to Stabil-TRAK Interlock Relay (Pin 87)
70C
9.92,
9.93 or
9.94
16 ORG/BLK Stabil-TRAK Lock Up Relay (Pin 86) to Stabil-TRAK Interlock Relay (Pin 87)
71
9.92,
9.93 or
9.94
16 ORG/WHT Stabil-TRAK Interlock Relay (Pin 30) to Boom Extend Interlock Relay (Pin 87A)
71A 9.94 16 ORG/WHT
~
Boom Extend Interlock Relay (Pin 87A) to Right Outrigger Lock Relay (Pin 86)
71B 9.94 16 ORG/WHT
~
Right Outrigger Lock Relay (Pin 86) to Left Outrigger Lock Relay (Pin 86)
Wire No. Page Gauge Color From - Function - To
‡ SN 13198 through 17984
~
SN 17985 through 19079
