ACCESS PANELS AND COVERS
4.7.1
Access Panel and Cover Replacement
Note: Refer to appropriate parts manual for mounting
hardware.
The vehicle is equipped with various access panels and
covers. Removal and installation are easily accomplished
by observing the mounting configurations as shown.
1. Hydraulic Oil Reservoir/
Fuel Tank Cover
2. Counterweight Cover
3. Transmission Cover,
Lower (Model 8042,
10042, 10054, S/N
14053 & After)
4. Transmission Cover,
Upper (Model 8042,
10042, 10054, S/N
14053 & After)
5. Side Door Cover,
Right
6. Transmission Cover
(Model 8042, 10042,
10054, S/N 14052 &
Before)
7. Rear Door Weldment
8. Side Door Cover, Left
MH3340
