9.83 Model 8042, 10042, 10054 Legacy Rev. 10/03
Electrical System
152B1 9.86 16 BLK/WHT § Male Connector to Splice 152B
152B2 9.86 16 BLK/WHT § Splice 152B to Park Brake Switch Connector (Pin 3)
153
9.84 or
9.86
16 GRY/WHT Park Brake Disconnect Relay (Pin 30) to Shifter Connector (Pin 9)
153A
9.84 or
9.86
16 GRY/WHT Transmission Fuse to Park Brake Disconnect Relay (Pin 30)
154
9.84 or
9.86
16 BLU/WHT Instrument Panel Connector (Pin J14) to Roadlights Connector (Option) (Main Beam)
155
9.84 or
9.86
16 GRN/RED Instrument Panel Connector (Pin J15) to Roadlights Connector (Option) (Turn Signals)
156
9.84 or
9.86
16 RED/WHT
Instrument Panel Connector (Pin J2)
to Roadlights Connector (Option) (Instrument Panel Backlight)
158
9.84 or
9.86
16 BLK Horn Button to Cab/Chassis Female Connector (Pin A5) (Cab Harness)
9.85 or
9.87
16 WHT Cab/Chassis Male Connector (Pin A5) to Horn Connector (–) (Engine Harness)
Wire No. Page Gauge Color From - Function - To
† SN 13198 through 16782 w/o Lighting Package
§ SN 13198 through 16782 w/Lighting Package and SN 16783 through 19079
