Electrical System
9.112 Model 8042, 10042, 10054 Legacy Rev. 10/03
9.7.34 Worklight Harness Electrical Schematic Legend
Wire No. Page Gauge Color Description
1
9.113
12 RED Splice 1 to Cab Harness Fuse Block Connector (Wire 12AA)
1A 14 RED Splice 1 to Worklight Switch (Pin 8)
1B 14 RED Splice 1 to Worklight Switch (Pin 2)
1C 14 RED Splice 1 to Worklight Switch (Pin 5)
2A 12 BLK Splice 2 to Cab Ground
2B1 16 BLK Splice 2 to Left Front Worklight (Pin N)
2B2 16 BLK Splice 2 to Right Front Worklight (Pin N)
2B3 16 BLK Splice 2 to Left Rear Worklight (Pin N)
2B4 16 BLK Splice 2 to Worklight Harness Connector (Pin B)
2B5 16 BLK Splice 2 to Right Rear Worklight (Pin N)
2C 14 BLK Splice 2 to Worklight Switch (Pin 7)
3A 14 LT BLU Worklight Switch (Pin 3) to Cab Harness Instrument Panel Connector (Wire 156)
3A1 14 LT BLU Splice 3 to Worklight Switch (Pin 3)
3B 14 LT BLU Splice 3 to Left Front Worklight (Pin P)
3C 14 LT BLU Splice 3 to Right Front Worklight (Pin P)
3D 14 LT BLU Splice 3 to Worklight Harness Connector (Pin A)
4A 14 YEL Splice 4 to Worklight Switch (Pin 6)
4B 14 YEL Splice 4 to Left Rear Worklight (Pin P)
4C 14 YEL Splice 4 to Right Rear Worklight (Pin P)
BOOMLIGHT HARNESS WIRES
2B
9.113
14 BLK Boom Worklight Harness Connector (Pin B) to Boom Light (Pin N)
3D 14 LT BLU Boom Worklight Harness Connector (Pin A) to Boom Light (Pin P)
