Page 701
Electrical System
9.110
Model 8042, 10042, 10054 Legacy
Rev. 10/03
9.7.32
Roadlight Harness Electrical Schematic Legend
Wire No.
Page
Gauge
Color
Description
1
12
RED
Splice 1 to Cab Harness Fuse Block Connector (Wire 12AA)
1A
14
RED
Splice 1 to Worklight Switch (Pin 5)
1B
14
RED
Splice 1 to Hazard Switch (Pin 8)
1C
14
RED
Splice 1 to Lighting Control Lever 3-Way Connector (Pin C)
1D
14
RED
Splice 1 to Brake Pedal Switch (Pin 4)
1E
14
RED
Splice 1 to Worklight Switch (Pin 2)
1F
14
RED
Splice 1 to Worklight Switch (Pin 8)
1J
14
RED
Jumper from Hazard Switch (Pin 8) to Hazard Switch (Pin 1)
2A
12
BLK
Splice 2
to Cab Ground Stud
2B
16
BLK
Splice 2 to Hazard Switch (Pin 10)
2C
16
BLK
Splice 2 to Boom Worklight Harness Connector (Pin B)
2D
16
BLK
Splice 2 to Left Rear Worklight (Pin N)
2E
16
BLK
Splice 2 to Left Taillight (Pin 1)
2F
16
BLK
Splice 2 to Right Taillight (Pin 1)
2G
16
BLK
Splice 2 to Right Rear Worklight (Pin N)
2H
16
BLK
Splice 2 to Right Front Roadlight (Pin 6)
2J
16
BLK
Splice 2 to Left Front Roadlight (Pin 6)
2K
16
BLK
Splice 2 to Worklight Switch (Pin 7)
3A
16
LT BLU
Worklight Switch (Pin 3) to Boom Worklight Harness Connector (Pin A)
4A
14
YEL
Splice 4 to Worklight Switch (Pin 6)
4B
14
YEL
Splice 4 to Left Rear Worklight (Pin P)
4C
14
YEL
Splice 4 to Right Rear Worklight (Pin P)
20
16
WHT
Splice 20 to Lighting Control Lever 3-Way Connector (Pin A)
20A
16
WHT
Splice 20 to Left Front Roadlight (Pin 2)
20B
16
WHT
Splice 20 to Right Front Roadlight (Pin 2)
20C
16
WHT
Splice 20 to Left Taillight (Pin 3)
20D
16
WHT
Splice 20 to Right Taillight (Pin 3)
20F
16
WHT
Splice 20 to Cab Harness Instrument Panel Connector (Wire 156)
21
16
RED
Splice 21 to Lighting Control Lever 3-Way Connector (Pin B)
21A
16
RED
Splice 21 to Left Front Roadlight (Pin 1)
21B
16
RED
Splice 21 to Right Front Roadlight (Pin 1)
21C
16
RED
Splice 21 to Cab Harness Fuse Block Connector (Wire 21C)
22
16
ORG
Splice 22 to Lighting Control Lever 6-Way Connector (Pin E)
22A
16
ORG
Splice 22 to Left Front Roadlight (Pin 3)
22B
16
ORG
Splice 22 to Left Taillight (Pin 2)
22C
16
ORG
Splice 22 to Hazard Switch (Pin 18)
23
16
GRN
Splice 23 to Lighting Control Lever 6-Way Connector (Pin D)
23A
16
GRN
Splice 23 to Right Front Roadlight (Pin 3)
23B
16
GRN
Splice 23 to Right Taillight (Pin 2)
23C
16
GRN
Splice 23 to Hazard Switch (Pin 17)
24
16
DK BLU
Splice 24 to Lighting Control Lever 6-Way Connector (Pin A)
24A
16
DK BLU
Splice 24 to Left Front Roadlight (Pin 4)
24B
16
DK BLU
Splice 24 to Right Front Roadlight (Pin 4)
24C
16
DK BLU
Splice 24 to Cab Harness Instrument Panel Connector (Wire 154)
25
16
PNK
Splice 24 to Lighting Control Lever 6-Way Connector (Pin B)
26
16
GRY
Splice 26 to Brake Pedal Switch (Pin 5)
26A
16
GRY
Splice 26 to Left Taillight (Pin 4)
26B
16
GRY
Splice 26 to Right Taillight (Pin 4)
27
16
PUR/WHT
Flasher (Pin P) to Cab Harness Instrument Panel Connector (Wire 155)
28
16
PUR
Splice 28 to Flasher (Pin L)
28A
16
PUR
Splice 28 to Lighting Control Lever 6-Way Connector (Pin F)
28B
16
PUR
Splice 28 to Hazard Switch (Pin 5)
31
16
YEL
Cab Harness Fuse Block Connector (Wire 23) to Lighting Control Lever 6-Way Connector (Pin C)
32
14
GRN
Cab Harness Fuse Block Connector (Wire 12C) to Hazard Switch (Pin 3)
33
16
PUR
Flasher (Pin X) to Hazard Switch (Pin 2)
BOOMLIGHT HARNESS WIRES
2B
14
BLK
Boom Worklight Harness Connector (Pin B) to Boom Light (Pin N)
3D
14
LT BLU
Boom Worklight Harness Connector (Pin A) to Boom Light (Pin P)
