9.139

Model 8042, 10042, 10054 Legacy

Rev. 10/03

Electrical System

Washer does not spray

water on front windshield

and skylight.

If OK

Not OK

Before troubleshooting any
electrical circuit, ALWAYS
begin by checking the
following:

1. All connections relating to

circuit are clean and tight.

Verify that both wipers are

operating properly.

Troubleshoot and fix.

Not

OK

Check hose connections.

Fix hose connections.

Not

OK

Check reservoir for

washer fluid.

Fill reservoir with

washer fluid.

Not

OK

If OK

If OK

Check for battery voltage on

washer switch connector at

Pins 3 and 8,

wires [6D] (RED/WHT) and

[6E] (RED/WHT).

If OK

Not

OK

Repair/replace
wiper harness.

With the washer switch

pressed, check for battery

voltage at Pin 2 at switch

connector.

If OK

Not

OK

Replace front washer switch.

Check for battery voltage at

wire [10] (GRN) at washer

pump motor connector.

If OK

Not

OK

Check for proper ground at

washer pump motor.

If OK

Not

OK

Clean, tighten and recheck.

Replace washer pump motor.

Repair/replace
wiper harness.
