Electrical System
9.10 Model 8042, 10042, 10054 Legacy Rev. 10/03
9.1.3 General Overview (Engine Harness) (SN 8042, 18991 - 19987, 10042 19031 - 19987,
10054, 19080 - 19987 And 8042/10042/10054, 0160002332 & After) (Continued)
MH5590
Engine
Harness
Continued.
See
Page 9.9
Grid
Heater
Relays
Engine
Grid
Heater
Engine
Starter
To
Engine
Starter
Diagnostic
Connector
Cold Start Grid
Heater Fuses
Terminating
Resistor
ECM
Connectors
Terminating
Resistor
Ground
Buss Bar
Diode VesPaks
ECM
Fuses
Engine
Alternator
Batteries
Frame
Ground
Stud
