June 2004 Isis® Sonar User's Manual, Volume1 50
Figure 3-13. Example of a message identifying event status change
3.6.1.4 Isis Explorer Help Menu Functions
• Information box with Isis Explorer version number and copyright
information.
• Clicking the Question Mark icon on the Toolbar (Figure 3-11) is
equivalent to choosing Isis Explorer→Help.
3.6.2 Isis Explorer Toolbar Buttons
The Isis Explorer has two toolbar iconized buttons: a playback button and a
menu button. They are shown in Figure 3-11.
• Click the right-pointing arrow button (►) to play the selected file(s)
in Isis.
• Click the Question Mark button ( ) to display the About
information box, which reveals the Isis Explorer version number and
copyright information.
3.6.3 Other Buttons and Fields in Isis Explorer
• Browse… button: Use this button to display the Windows file dialog
for navigating to the desired file path. The selected path is then
shown in the Path label box.
• File Sorting panel: The Isis Explorer tool provides five types of
sorting: primary, secondary, tertiary, ascending, and descending.
Primary, secondary, and tertiary choices offer drop-down list boxes
for setting the sorting item: by Average Heading (CMG), End Time,
File Name, Range Scale (Rng), Sensor Type, File Size, or Start
Time. The default is to sort by file name.
• The lower right corner of the main dialog box displays a colored box
to indicate the connection status with Isis: Green denotes an active
Chapter 3: Using the File Menu
