June 2004 Isis® Sonar User's Manual, Volume 1
236
The 2-D Wiggle Display dialog box displays the parameters you get when
you have a common (non-wiggle) waterfall imagery scrolling on your screen
(Figure 10-2), but the 2-D Wiggle Display dialog box adds a few more
parameters (Table 10-2).
Table 10-2. Additional waterfall parameters for 2-D wiggle
imagery
Channel
Display A single channel can be displayed in each Wiggle
window. Each Wiggle window displays, by default, the last
available channel. Select the channel that you wish to
display in this window.
Amplitude The Amplitude slide bar controls the gain of the signal in
each trace for the Wiggle display only.
Filter The Filter slide bar controls the amount of averaging done
within each trace. The number to the right represents the
number of samples that are averaged for each point on
the trace. A larger Filter number results in a smoother
trace.
Trace Offset This slide bar controls the spacing between traces.
Color Select the colors for the trace, the fill and the window
background.
Display Type The wiggle traces can be unfilled, the positive portions of
the wiggle can be filled, or the negative portions of the
wiggle can be filled. Positive is to the right in 2-D Wiggle
windows and positive is up in 3-D Wiggle windows.
Chapter 10: Using the Window Menu
