June 2004 Isis® Sonar User's Manual, Volume1 221
Table 9-9. The Subbottom Picking and Tracking dialog box
Function Name Possible Actions Effect of Actions Taken
Tracking
Suspend
Click to darken or clear a
numbered radio button. Disables all picking, tracking and
file operations (when button is
dark) or enabled (when button is
clear).
Manual Click to darken or clear a
numbered radio button. The operator, not Isis, picks all
reflectors.
Automatic Click to darken or clear a
numbered radio button. Isis picks the picked reflector
without requiring your further help;
this is the default case.
Look-ahead
Look-ahead
(pings) Click on left or right arrows
of slide-bar. not currently active; for future
release; will allow Isis to track
reflectors by looking ahead into
the file and weighing the results of
each possible tracking decision.
Reflector
Reflector number
(19)
Click to darken or clear a
numbered radio button. Selects a reflector to be defined
and tracked. The currently
selected reflector will be shown by
a red line. All others will be shown
in green.
Chapter 9: Using the Tools Menu
