June 2004 Isis® Sonar User's Manual, Volume1
215
Table 9-7. Required tokens in an SPN file
Token
Meaning
Valid Range or Units
{DAY}
Day [1,31]
{MON}
Month [1,12]
{YRS}
Year four
digits
{HRS}
Hour [0,23]
{MIN}
Minute [0,59]
{SEC}
Second [0.0,60.0]
{LAT} or {NTH}
Latitude or
Northing
(degrees) +east/-west or
meters
{LON} or {EST}
Longitude or
Easting
(degrees) +north/-south or
meters
Table 9-8. Optional tokens in an SPN file
Token
Meaning
Valid Range or Units
{KMP}
Kilometers Pipe
meters
{PNG}
Ping Number
{FHM}
Fish height from Isis
meters
{FHB}
Fish height from bottom track
meters
{PDT}
Distance off track to pipe
meters
{SEC}
Second [0.0,60.0]
{SHT}
Span Height
meters
{SHM}
Span Height Maximum
meters
Chapter 9: Using the Tools Menu
