June 2004 Isis® Sonar User's Manual, Volume1
121
Figure 8-3: Depth Delay and Duration dialog box
Meanings of the options in the Depth Delay and Duration dialog box appear in
Table 8-1.
Table 8-1. Depth Delay and Duration options
Apply Settings to
(radio buttons)
All Channels the Same — the chosen values will
apply to all channels used in your data.
Each Channel set Different — means you have to
set your values separately for each channel used.
You will have to click OK for each change so made.
Clicking Reset All Settings does the following:
• Sets All Channels the Same in Apply
Settings to.
• Sets Units to Off.
• Sets Start Point specified as to Delay.
• Makes the Reference Depth and Duration
slider bars inaccessible (grayed out).
Chapter 8: Using the View Menu
