Intel® PXA26x Processor Family Developer’s Manual
17-31
Hardware UART
17.6
Hardware UART Register Summary
contains the register addresses for the HWUART.
2
R/W
XMODE
TRANSMIT PULSE WIDTH SELECT:
When XMODE is cleared, the UART 16X clock is used to clock the IrDA
transmit and receive logic. When XMODE is set, receive decoder operation
does not change and the transmit encoder generates 1.6
µ
s pulses (that
are 3/16 of a bit time at 115.2 Kbps) instead of pulses 3/16 of a bit time
wide.
0 – Transmit pulse width is 3/16 of a bit time wide
1 – Transmit pulse width is 1.6
µ
s
1
R/W
RCVEIR
RECEIVER SIR ENABLE:
When RCVEIR is set, the signal from the RXD pin is processed by the IrDA
decoder before it is fed to the UART. If RCVEIR is cleared, then all clocking
to the IrDA decoder is blocked and the RXD pin is fed directly to the UART.
0 – Receiver is in UART mode
1 – Receiver is in infrared mode
0
R/W
XMITIR
TRANSMITTER SIR ENABLE:
When XMITIR is set to a 1, the normal TXD output from the UART is
processed by the IrDA encoder before it is fed to the device pin. If XMITIR is
cleared, all clocking to the IrDA encoder is blocked and the UART’s TXD
signal is connected directly to the device pin.
When transmitter SIR enable is set, the TXD output pin, which is in a
normally high default state, will switch to a normally low default state. This
can cause a false start bit unless the infrared LED is disabled before
XMITIR is set.
0 – Transmitter is in UART mode
1 – Transmitter is in infrared mode
Table 17-19.
ISR
Bit Definitions (Sheet 2 of 2)
Physical Address
0x4160_0020
Infrared Selection Reg. (ISR)
PXA26x Processor Family Hardware
UART
User
Settings
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
Reserved
RX
PL
TXP
L
XM
O
D
E
RC
VEIR
XM
ITIR
Reset
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
0
0
0
0
0
Bits
Access
Name
Description
Table 17-20. HWUART Register Locations (Sheet 1 of 2)
Register
Addresses
DLAB Bit
Value
Name
Description
0x4160 0000
0
HWRBR
“Receive Buffer Register (RBR)”
(read only)
0x4160 0000
0
HWTHR
“Transmit Holding Register (THR)”
(write only)
0x4160 0004
0
HWIER
“Interrupt Enable Register (IER)”
(read/write)
