Page 576

16-28
Intel® PXA26x Processor Family Developer’s Manual
Network/Audio Synchronous Serial Protocol Serial Ports
16.5.4
SSP Time Out Register (SSTO)
SSP Time Out Register, shown in
,specifies the time-out value used to signal a period of
inactivity within the receive FIFO.
These are read/write registers. Ignore reads from reserved bits. Write zeros to reserved bits.
3
R/W
ETDS
END OF TRANSFER DATA STATE:
Determines the state of SSPTXD at the end of a transfer. When cleared,
the state of SSPTXD is forced to 0 after the last bit (bit 0) of the frame is
sent and remains 0 through the next idle period. When set, the state of
SSPTXD retains the value of the last bit sent (bit 0) through the next idle
period.
0 – Low
1 – Last Value
2
R/W
SFRMP
SERIAL FRAME POLARITY:
Determines the active state of the Serial Frame signal (SSPSFRM).
In Idle mode or when the SSP is disabled, SSPSFRM is in its inactive
state. In slave mode (SSCR1[SFRMDIR] set), this bit indicates the
polarity of the incoming frame signal.
0 – SSPSFRM is active low.
1 – SSPSFRM is active high.
1:0
R/W
SCMODE
SERIAL BIT-RATE CLOCK MODE:
Selects one of four serial clock modes when the PSP is selected
(SSCR0[FRF]=0b11).
Its operation is similar to how SSCR1[SPO] and SSCR1[SPH] together
determine the idle state of SSPSCLK and on which edges data is driven
and sampled.
0b00 - Data Driven (Falling), Data Sampled (Rising), Idle State (Low)
0b01 - Data Driven (Rising), Data Sampled (Falling), Idle State (Low)
0b10 - Data Driven (Rising), Data Sampled (Falling), Idle State (High)
0b11- Data Driven (Falling), Data Sampled (Rising), Idle State (High)
Table 16-5.
SSPSP Bit Definitions (Sheet 2 of 2)
Physical Address
Base + 0x2C
SSPSP
PXA26x processor family Network/Audio
SSP Serial Ports
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
Reserved
DM
YSTO
P
R
eser
ved
SFRMWDTH
SFRMDLY
DM
Y
S
T
RT
STRTD
L
Y
ETD
S
SFRM
P
SC
M
O
D
E
Reset
?
?
?
?
?
?
?
0
0
?
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bits
Access
Name
Description
