Intel® PXA26x Processor Family Developer’s Manual 14-13
Inter-Integrated Circuit Sound Controller
14.6.4 Serial Audio Clock Divider Register (SADIV)
This register is used for generating six different BITCLK frequencies and hence six different
sampling frequencies. All bits are read/write.
Table 14-8 shows the bit layout of SADIV.
The reset value, 0x0000001A, defaults to a sampling frequency of 22.05 KHz.
Note: Setting this register to values other than those shown in Table 14-2, “Supported Sampling
Frequencies” on page 14-6 is not allowed and will cause unpredictable activity.
14.6.5 Serial Audio Interrupt Clear Register (SAICR)
The Serial Audio Interrupt Clear Register (SAICR) is the Interrupt Control Register. This is only an
addressable location and no data is actually stored. These addressable locations are used only for
clearing status register (SASR0) bits. Each bit position corresponds to an interrupt source bit
position in the Status register.
Table 14-9 shows the bit layout of SAICR.
This is a write-only register. A read operation will be treated as a read from a reserved location.
The reset value is reserved, since the register cannot be read.
Table 14-8. SADIV Bit Descriptions
Physical Address
0x4040-0060
Serial Audio Clock Divider
Register
I 2 S Controller
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved SADIV
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 0 1 0
Bits Name Description
31:7 — Reserved
6:0 SADIV
Audio clock divider. Valid SADIV(6:0) are:
000 1100 – BITCLK of 3.072 MHz
000 1101 – BITCLK of 2.836 MHz
001 1010 – BITCLK of 1.418 MHz
010 0100 – BITCLK of 1.024 MHz
011 0100 – BITCLK of 708.92 KHz
100 1000 – BITCLK of 512.00 KHz
