Intel® PXA26x Processor Family Developer’s Manual
6-39
Memory Controller
shows sample frequency configurations for programming non-SDRAM timing fast
flash. When in doubt, the higher frequency configuration and corresponding CAS latency must be
used.
Table 6-18. Read Configuration Register Programming Values
Bits
Field Name
Value to Program
2:0
BURST LENGTH
010
8 Word Burst
5:3
RESERVED
000
6
CLOCK CONFIGURATION
1
Use rising edge of clock
7
BURST SEQUENCE
1
Linear burst Order
(INTEL BURST ORDER IS NOT SUPPORTED)
8
WAIT CONFIGURATION
N/A
nWAIT from the flash device is ignored by the
processor.
9
DATA OUTPUT CONFIGURATION
0
Hold data for one clock
10
RESERVED
0
13:11
FREQUENCY CONFIGURATION
010 – CAS Latency 3
011 – CAS Latency 4
100 – CAS Latency 5
101 – CAS Latency 6
110 – CAS Latency 7
Chosen based on the AC Characteristics – Read only
Operation section of the flash device data sheet
14
RESERVED
0
15
READ MODE
0 – Synchronous Operation
1 – Asynchronous Operation
Table 6-19. Frequency Code Configuration Values Based on Clock Speed (Sheet 1 of 2)
MEMCLK
Frequency
SDCLK0
Frequency
MDREFR:
K0DB2
Valid
Frequency
Configurations
Corresponding
CAS Latencies
20
20
0
2 / 3 / 4 / 5 / 6
3 / 4 / 5 / 6 / 7
33
33
0
3 / 4 / 5 / 6
4 / 5 / 6 / 7
50
50
0
4 / 5 / 6
5 / 6 / 7
25
1
2 / 3 / 4 / 5 / 6
3 / 4 / 5 / 6 / 7
66
66
0
5 / 6
6 / 7
33
1
3 / 4 / 5 / 6
4 / 5 / 6 / 7
100
50
1
4 / 5 / 6
5 / 6 / 7
118
59
1
5 / 6
6 / 7
